DC Axial Fan

  • 1804 3.3V 5VDC (18X18X4mm) Cooling Fan
  • 1804 3.3V 5VDC (18X18X4mm) Cooling Fan
  • 1804 3.3V 5VDC (18X18X4mm) Cooling Fan
1804 3.3V 5VDC (18X18X4mm) Cooling Fan1804 3.3V 5VDC (18X18X4mm) Cooling Fan1804 3.3V 5VDC (18X18X4mm) Cooling Fan

1804 3.3V 5VDC (18X18X4mm) Cooling Fan

  • Product description: 1804 - DC Axial Fan 18x18x4mm 3.3VDC 5VDC Sleeve/Hydraulic Bearing 0.025m³/min 0.90CFM - DC brushless axial fans and quiet cooling solutions from Cooling Technology.
  • INQUIRY

18x18x4mm 3.3V 5V DC Cooling Fan

Product Attributes

Size / Dimension: 18x18x4mm

Voltage - Rated3.3VDC / 5VDC

Bearing Type: Sleeve / Hydraulic Bearing

Air Flow: 0.018 - 0.025 m³/min(0.65 - 0.90CFM

Static Pressure: 1.95 - 3.5 mm H2O(0.077 - 0.138 in H2O

Noise: 25 / 35dB(A)

RPM: 85000 / 13000 RPM

Current Rating (Amps): 0.03 - 0.04A

Voltage Range: 2 ~ 6VDC

Material - Frame: Plastic (Flammability: UL94V-0)

Material - Blade: Plastic (Flammability: UL94V-0)

Power (Watts)0.1 - 0.2 W



Certifications:

CE & FCC Listed

REACH Compliant



Model Rated Voltage Operating Voltage Range Rated Current
Rated
Input Power
Speed Maximum Air Flow Maximum Air Pressure Noise
PART.NO. VDC VDC Amp Watt R.P.M M³/min CFM mmH2O InH2O dB-A
CLD1804L33X 3.3 2~6 0.03 0.1 8500 0.018 0.65 1.95 0.077 25
CLD1804L05X 5 2~6 0.04 0.2 13000 0.025 0.90 3.50 0.138 35
